| SKU | WATTAGE | OUTPUT | CCT | CRI | VOLTAGE | REPLACES | UL | DLC | DLC ID |
| J-LHB06135W27V50KD | 135W | 19,400 Lumens | 5000K / 4000K | 70 | 120-277V / 347-480V | 250W MH | Wet Locations | Premium | PXS5F186 |
| J-LHB06175W27V50KD | 175W | 25,600 Lumens | 5000K / 4000K | 70 | 120-277V / 347-480V | 320W MH | Wet Locations | Premium | PX344LYK |
| J-LHB06200W27V50KD | 200W | 29,800 Lumens | 5000K / 4000K | 70 | 120-277V / 347-480V | 400W MH | Wet Locations | Premium | PM083BYO |
Visit the Design Lights Consortium website for more information on product DLC qualification.
Optional Motion Sensor And Battery Backup Available
Series J-LHB06 Circular UFO LED High Bay lights are designed to provide reliable illumination for large retail, industrial, and institutional spaces with high ceilings. They are an energy-efficient replacement for traditional metal halide high bays, and are an ideal choice for settings where retaining the traditional look of metal halide fixtures is important.
Optional accessories include an integrated center-mounted multi-level motion sensor, and external emergency battery backup box, and an aluminum reflector.
Applications
WAREHOUSES, WORKSHOPS, CONVENTION CENTERS, GYMNASIUMS, FACTORIES
Customer-Focused Features
|
OPTIMAL MATERIALS Die-Cast
Aluminum Housing and Clear
Polycarbonate Lens
|
DIMMING CONTROLS 1-10V
Dimmable Control Allows for
Customized Lighting Outputs
|
|
OPERATING TEMPERATURES Rated for
Temperatures from -40˚F to 131˚F
(-40˚C to 55˚C)
|
MEETS ANSI/IEEE C62.41.2
Integrated 6KV Surge Protection
|
135W/175W/200W
